MSFS20 MSFS Glass material (Blender)

I know, try to Flip the normals of the windshield faces, they must point inside your mesh



Inviato dal mio Mi 9 Lite utilizzando Tapatalk

I followed the advice and I got it for the jetway glass


Attachments

  • Microsoft Flight Simulator Screenshot 2021.08.19 - 17.34.13.91.png
    Microsoft Flight Simulator Screenshot 2021.08.19 - 17.34.13.91.png
    3.7 MB · Views: 320
Still disappear from the cockpit, how did they get it to work I don't get it
According you are talking about the screenshot from pilotplus you have attached, that obviouly is not taken from a cocktpit, but from the drone/showcase camera

From the cockpit there is (to me) no reason to render the rain effect on every other surface, is is already render on the cockpit windshield, are you able really to tell the difference?

Please forgive me you non italian people:
---
"it's not working really great for me, when I'm inside the cockpit I don't see the glass."
Rileggendo il tuo commento sembra che il tuo problema sia che mettendo il material windshield sparisca il vetro da dentro il cocktpit, infatti è proprio per quello che ti ho suggerito di duplicare i poligoni del vetro!

Se vuoi il vetro (con il suo colore, riflettente etc)+l'effetto pioggia devi fare:
- una mesh con i suoi poligoni con materiale standard/msfs glass, con i normals puntati verso l'esterno
- duplichi la mesh, ne flippi i normals e assegni il materiale windshield
- se vuoi anche andare all'interno dell'oggetto (torre/terminal che sia), duplichi ancora la mesh e assegni di nuovo material msfs glass/standard con i normals verso l'interno

Insomma, per un vetro completo io uso tre mesh separate, se vuoi vedere l'effetto la torre e le vetrate di fronte al pargheggio del mio Trento sono fatte così


:wizard:

According you are talking about the screenshot from pilotplus you have attached, that obviouly is not taken from a cocktpit, but from the drone/showcase camera

From the cockpit there is (to me) no reason to render the rain effect on every other surface, is is already render on the cockpit windshield, are you able really to tell the difference?

Please forgive me you non italian people:
---
"it's not working really great for me, when I'm inside the cockpit I don't see the glass."
Rileggendo il tuo commento sembra che il tuo problema sia che mettendo il material windshield sparisca il vetro da dentro il cocktpit, infatti è proprio per quello che ti ho suggerito di duplicare i poligoni del vetro!

Se vuoi il vetro (con il suo colore, riflettente etc)+l'effetto pioggia devi fare:
- una mesh con i suoi poligoni con materiale standard/msfs glass, con i normals puntati verso l'esterno
- duplichi la mesh, ne flippi i normals e assegni il materiale windshield
- se vuoi anche andare all'interno dell'oggetto (torre/terminal che sia), duplichi ancora la mesh e assegni di nuovo material msfs glass/standard con i normals verso l'interno

Insomma, per un vetro completo io uso tre mesh separate, se vuoi vedere l'effetto la torre e le vetrate di fronte al pargheggio del mio Trento sono fatte così


:wizard:
Thanks! Grazie mille!

Hello everyone, I have a problem with the glass in the terminal at night with lights inside the 3d, I used glass in blender with texture, with external view during the day everything is fine, reflections, color transparency, at night with standard material the interior looks good and gives a natural color, while with glass material the color of the interior is merged (external view) with the color of the glass (in this case blue/cyan texture) is there a way to solve it or should I resign myself and use standard material? thank you

According you are talking about the screenshot from pilotplus you have attached, that obviouly is not taken from a cocktpit, but from the drone/showcase camera

From the cockpit there is (to me) no reason to render the rain effect on every other surface, is is already render on the cockpit windshield, are you able really to tell the difference?

Please forgive me you non italian people:
---
"it's not working really great for me, when I'm inside the cockpit I don't see the glass."
Rileggendo il tuo commento sembra che il tuo problema sia che mettendo il material windshield sparisca il vetro da dentro il cocktpit, infatti è proprio per quello che ti ho suggerito di duplicare i poligoni del vetro!

Se vuoi il vetro (con il suo colore, riflettente etc)+l'effetto pioggia devi fare:
- una mesh con i suoi poligoni con materiale standard/msfs glass, con i normals puntati verso l'esterno
- duplichi la mesh, ne flippi i normals e assegni il materiale windshield
- se vuoi anche andare all'interno dell'oggetto (torre/terminal che sia), duplichi ancora la mesh e assegni di nuovo material msfs glass/standard con i normals verso l'interno

Insomma, per un vetro completo io uso tre mesh separate, se vuoi vedere l'effetto la torre e le vetrate di fronte al pargheggio del mio Trento sono fatte così


:wizard:
Come fai ad evitare i bug che si creano con il glass quando osservi un vetro attraverso un vetro?

Bug? Forse intendi l'immagine riflessa?
Quella che sembra un'astronave? Metti deformation factor a 0


Inviato dal mio Mi 9 Lite utilizzando Tapatalk

Bug? Forse intendi l'immagine riflessa?
Quella che sembra un'astronave? Metti deformation factor a 0


Inviato dal mio Mi 9 Lite utilizzando Tapatalk
Mi sono espresso male, non intendevo quella ma l'effetto strano che si crea quando guardi una finestra e dietro hai una parete con un vetro, lo vedi ad intermittenza scuro, mentre con standard va bene, visto che ci sei :) se hai tempo sapresti per cortesia darmi qualche info alla domanda che ho fatto sopra, grazie
