Why is not my animation working in MSFS

E

ErlandMatz

Messages
24
Country
sweden
Is There anyone that could help me to see what is missing in my testproject for an simple animation
(Just an AC that should have a rotating fan)
I have done it from Fredrico Pinittis tutorial
on Youtube.

All works fine in Blender and also Export works fine. But - and a big But - It is included in MSFS as an Sceneryobject but
no animation :(:(:(:(

In the model xml-file I have included a animation tag with a guid from the Free guid generator. All as Fredrico shows to do.

This tag is below the LODS tags in this modelinfo-xml.

// ********************************************************************//
<?xml version="1.0" encoding="utf-8"?>
<ModelInfo guid="{e4fa91f3-0934-429b-bc5d-b87c890ad177}" version="1.1">
<LODS>
<LOD minSize="0" ModelFile="AC-Cond-Anim.gltf"/>
</LODS>

<Animation name="AC_Cond_Fan" guid="{178ed8f9-083a-40fd-861b-7e742fe952c4}" type="Standard" typeParam="Autoplay"/>

</ModelInfo>
// ********************************************************************//


I have three blend-files in the zip.
One with no animation at all. The other have animations.

One is animating and NOT Pushed down from the action editor in the Dopesheet.
One is animation and IS Pushed down to a NLA-track (This is what Fredrico shows in the tutorial).
I have tested this with both Actions and NLA-tracks in the Animation Mode. (attachment is NLA-tracks I think)

Everyone is working fine in Blender but will not spin in blender.
Even the Windows standard 3D viewer is not showing any animation and for me this shows that the problem is
probably in the export from blender and something I have missed there. (This is my first attempt to export an animation )

My version of Blender is 3.6.12 and Asobo-exporter is 1.3.3

Have attached a zip with 3 blend-files, and the only image that is used there as an image.

Hope anyone can help me with this. What have I done wrong? What have I missed?

Greatful for all tips I can have from you.

// Erland





Attachments

Hi.
Your animation GUID must not have brackets:
<Animation name="AC_Cond_Fan" guid="178ed8f9-083a-40fd-861b-7e742fe952c4" type="Standard" typeParam="Autoplay"/>
